TISCO BAOSTEEL 316Ti Stainless Steel Plate 1.0 - 30.0mm CR HR SS Plate 316Ti Stainless
We are one of the Leading Manufacturer And Exporter of High Quality Stainless Steel 316TI Plate, which is slow to harden when being worked on and most welding methods are sufficient to yield desired results. In terms of working, both hot and cold working practices can be applied; however, these Stainless Steel 316Ti Sheets does not harden in response to hot working, only cold. Our Stainless Steel 316Ti Plates is a high – alloy austenitic stainless-steel with little carbon content, where the quality is meant for use under serious corrosive conditions. These Stainless Steel 316Ti Coils had been application proven over several years and was initially designed to withstand corrosion in dilute sulfuric acid.
Our Stainless Steel 316Ti Slating Coils will be standardized and also authorized for pressure vessel utilize in many nations. Structurally, this Stainless Steel 316Ti Perforated Coils is completely austenitic it is much less too sensitive to precipitation ferrite and as well sigma phases compared to conventional austenitic grades with higher molybdenum content. Characteristically, because of the mixture of relatively higher contents of chromium, nickel, molybdenum and copper, our 316Ti Stainless Steel Sheets provides high – quality resistance to basic corrosion, especially in sulfuric and also phosphoric conditions.
Stainless Steel 316TI Plate | Stainless Steel 316TI Plate | Stainless Steel 316TI Plate | Stainless Steel 316TI Plate | Stainless Steel 316TI Plate | Stainless Steel 316TI Plate | Stainless Steel 316TI Plate
The addition of copper to these 316Ti Stainless Steel Plates provides corrosion protected properties more advanced than the conventional chrome nickel stainless steel, specifically to sulphuric, phosphoric and as well acetic acids.
Stainless Steel 316TI Sheet, Plate & Coil Specifications |
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand
blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
SS 316TI Plate, Sheet & Coil Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
Stainless Steel 316TI Sheets, Plates & Coils Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Equivalent Grades for 316TI Stainless Steel Sheets & Plates
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
SS 316TI Sheets, Plate & Coils Application Industries
- Off-Shore Oil Drilling Companies
- Power Generation
- Petrochemicals
- Gas Processing
- Specialty Chemicals
- Pharmaceuticals
- Pharmaceutical Equipment
- Chemical Equipment
- Sea Water Equipment
- Heat Exchangers
- Condensers
- Pulp and Paper Industry
Stainless Steel 316TI Sheets, Plate & Coils Test Certificates
We provide Manufacturer TC (Test Certificate) in accordance to EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report. We also provide Standard certificates like EN 10204 3.1 and additional requirement like. NACE MR 01075. FERRIT CONTENT as per norms if requested by clients.
• EN 10204/3.1B,
• Raw Materials Certificate
• 100% Radiography Test Report
• Third Party Inspection Report, etc.
We ensure that all our materials go through strict quality tests before dispatching them to our clients.
• Mechanical Testing Such as Tensile of Area
• Hardness Test
• Chemical Analysis – Spectro Analysis
• Positive Material Identification – PMI Testing
• Flattening Test
• Micro and Macro Test
• Pitting Resistance Test
• Flaring Test
• Intergranular Corrosion (IGC) Test
• Commercial Invoice which includes HS Code
• Packing List including net weight and gross weight, number of boxes, Marks and Numbers
• Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
• Fumigation Certificates
• Raw Material Test Reports
• Material Traceability Records
• Quality Assurance Plan (QAP)
• Heat Treatment Charts
• Test Certificates certifying NACE MR0103, NACE MR0175
• Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
• Guarantee Letter
• NABL approved Laboratory Test Reports
• Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
• Form A for the purposes of the Generalized System of Preferences (GSP)
Stainless Steel 316TI Plate
