Hot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FT

Brand Name : TISCO BAOSTEEL

Model Number : UNS S30403 / 304L

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 4000-6000 USD/Ton

Payment Terms : T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Plate

Grade : UNS S30403 / 304L

Width : 1500mm 1219mm 1000mm

Surface : NO.1 2B

Brand : POSCO TISCO BAOSTEEL

Standard : ASTM A240/240M

Loading Port : Shanghai Port

Thickness : 0.6 - 30.0mm

Contact Now

Hot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FT

Specification of SS 304L plate

specifications
 ASTM A240 / ASME SA240, EN 10088-2
 Standard
 ASME, ASTM, DIN, BS, EN
Thickness
 1 to 200mm
Length
 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface
 2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand
blast, etc
Origin
 China
Technique
 Cold Rolled and Hot Rolled
Width
 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Stainless Steel Sheet Finish
 Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D
MTC
 Available as per EN 10204 3.1, Mill Test Certificate
Brand Name
 TISCO BAOSTEEL POSCO JISCO LISCO
Container
 40ft HC: 12032m
Form
 Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc.
Price term CFR, Ex-Work, FOB, CNF, CIF
Size
 40ft GP: 12032mm x 2352mm x 2393mm
20ft GP: 5898mm x 2352mm x 2393mm



Detail Size of 304L Stainless Steel Plate We have



Grade 304L / S30403
Thickness

Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm

Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm
Standard Size 1000*2000mm 1219*2438mm 1500*6000mm



Type 304L Stainless Steel

Type 304L stainless steel is an extra-low carbon version of the 304 steel alloy. The lower carbon content in 304L minimizes deleterious or harmful carbide precipitation as a result of welding. 304L can, therefore, be used "as welded" in severe corrosion environments, and it eliminates the need for annealing.



This grade has slightly lower mechanical properties than the standard 304 grade, but is still widely used thanks to its versatility. Like Type 304 stainless steel, it's commonly used in beer-brewing and wine-making, but also for purposes beyond the food industry such as in chemical containers, mining, and construction. It is ideal for use in metal parts such as nuts and bolts that are exposed to salt water.



304 Stainless Physical Properties:

  • Density: 8.03g/cm3
  • Electrical resistivity: 72 microhm-cm (20C)
  • Specific Heat: 500 J/kg °K (0-100°C)
  • Thermal conductivity: 16.3 W/m-k (100°C)
  • Modulus of Elasticity (MPa): 193 x 103 in tension
  • Melting Range: 2550-2650°F (1399-1454°C)

Type 304 and 304L Stainless Steel Composition:



Element Type 304 (%) Type 304L (%)
Carbon 0.08 max. 0.03 max.
Manganese 2.00 max. 2.00 max.
Phosphorus 0.045 max. 0.045 max.
Sulfur 0.03 max. 0.03 max.
Silicon 0.75 max. 0.75 max.
Chromium 18.00-20.00 18.00-20.00
Nickel 8.00-10.50 8.00-12.00
Nitrogen 0.10 max. 0.10 max.
Iron Balance Balance



Application of 304L Stainless Steel Plate



Alloy 304L Stainless Steel is used in a wide variety of home and commercial applications, including:

  • Food processing equipment, particularly in beer brewing, milk processing, and wine making
  • Kitchen benches, sinks, troughs, equipment, and appliances
  • Architectural trim and molding
  • Automotive and aerospace structural use
  • Construction material in large buildings
  • Chemical containers, including for transport
  • Heat exchangers
  • Nuts, bolts, screws, and other fasteners in the marine environment
  • Dyeing industry
  • Woven or welded screens for mining, quarrying & water filtration

 Hot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FTHot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FTHot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FTHot Rolled Stainless Steel Plate 304L / UNS S30403 SS Plate from BAOSTEEL 5FT*20FT
