304L stainless steel Strip introduction
304L stainless steel is a low-carbon austenitic stainless steel, which belongs to the low-carbon version of 304 stainless steel. Its low carbon content reduces carbide precipitation during welding, thus improving corrosion resistance after welding. 304L stainless steel tape is widely used in areas requiring good corrosion resistance and formability.
argument
Chemical composition (%) of 304L Stainless Steel Strips
- Carbon (C): ≤0.030
- Silicon (Si): ≤1.00
- Manganese (Mn): ≤2.00
- Phosphorus (P): ≤0.045
- Sulfur (S): ≤0.030
- Chromium (Cr): 18.0-20.0
- Nickel (Ni): 8.0-12.0
Mechanical property of 304L Stainless Steel Strips
- Tensile strength (MPa): ≥485
- Yield strength (MPa): ≥170
- Elongation (%): ≥40
- Hardness (HB): ≤201
Physical property of 304L Stainless Steel Strip
- Density: 7.93 g/cm³
- Melting point: 1400-1450°C
- Coefficient of thermal expansion: 17.2μm /m·°C (20-100°C)
- Thermal conductivity: 16.2 W/m·K (100°C)
- Resistivity: 0.72 Ω·mm²/m
property
Corrosion resistance
Excellent performance in most oxidizing and reducing media, especially suitable for use in chlorine-containing environments.
weldability
Low carbon content reduces carbide precipitation during welding and improves corrosion resistance after welding.
formability
It has good cold and hot processing properties and is easy to form and weld.
Low temperature performance
It still maintains good toughness and strength under low temperature environment.
Dimension parameter
The size parameters of 304L stainless steel tape can be customized according to specific needs, and the common
Size ranges are as follows:
- Thickness: 0.1mm-3.0mm
- Width: 10mm-1000mm
- Length: Can be customized according to requirements, the common length is 1000mm-6000mm
Apply of 304L Stainless Steel Strips
- Chemical industry: Used in the manufacture of reactors, storage tanks, pipelines, etc., because of its corrosion resistance, suitable for processing acid, alkali, salt and other media.
- Food processing: Used in the manufacture of food processing equipment and containers because they are easy to clean and resistant to corrosion.
- Construction industry: Used for decorative and structural materials, such as curtain walls, handrails, etc., because of their beauty and corrosion resistance.
- Medical device: Used in surgical instruments, implants, etc., thanks to its biocompatibility and corrosion resistance.
- Automobile industry: Used in exhaust and fuel system components due to high temperature and corrosion resistance.
- Energy industry: Used in nuclear power plants, oil and gas equipment because of its resistance to high temperatures and corrosion.
- Household appliance: Used in the manufacture of kitchen equipment, dishwashers, refrigerators, etc., because of its aesthetics and corrosion resistance.
Due to its low carbon content, 304L stainless steel tape has excellent corrosion resistance, welding performance and formability, and is widely used in chemical, food processing, construction, medical, automotive, energy and household appliances and other fields. Its size parameters can be customized according to specific requirements to meet the needs of different application scenarios.
